Genesis 22965002 22/6 Stranded Shielded + 22/4 Stranded Shielded + 22/2 Stranded Shielded + 18/4 Stranded Shielded Composite Access Control Cable, Riser, CMR, FT4, 500' (152.4 m) Reel, Yellow
22965002|WG-22965002
Genesis 22965002 22/6 Stranded Shielded + 22/4 Stranded Shielded + 22/2 Stranded Shielded + 18/4 Stranded Shielded Composite Access Control Cable, Riser, CMR, FT4, 500' (152.4 m) Reel, Yellow
22965002|WG-22965002
Genesis
Genesis 22965002 22/6 Stranded Shielded + 22/4 Stranded Shielded + 22/2 Stranded Shielded + 18/4 Stranded Shielded Composite Access Control Cable, Riser, CMR, FT4, 500' (152.4 m) Reel, Yellow
22965002 | WG-22965002
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Genesis Access Control Cables simplify and expedite wiring of access points by combining individual lock power, door contact, card reader, and request-to-exit cables into a single, easy-to-pull bundle.
Main Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- Polypropylene insulation
- All-components shielded for extra protection in noisy environments
- PVC jacket
- Durable rip cord for efficient jacket stripping and removal
- Countdown Length Markings for easy tracking of usage and remaining cable
- Rated for 300 Volts
- Rated for -20 °C to 75 °C
- Sunlight Resistant (UV) Rated
- REACH/RoHS Compliant
General Information
Name: Genesis 22965002 22/6 Stranded Shielded + 22/4 Stranded Shielded + 22/2 Stranded Shielded + 18/4 Stranded Shielded Composite Access Control Cable, Riser, CMR, FT4, 500' (152.4 m) Reel, Yellow
Category: Genesis, Wire & Cable, Security & Access Control Cables, Composite Cables
UPC Code: 886618208249
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number WG-22965002 Brand Name Genesis Manufacturer Genesis Cable Manufacturer Part Number 22965002 Packaged Quantity 1 Product Line Profusion Access Control Cable Product Model 22965002 Product Name 22965002 - Riser Composite Access Control, Yellow, 500 FT. Reel Product Type Access & Security Cable
American Wire Gauge 18AWG, 22AWG Cable Rating Riser Cable Type Composite Conductor Count 16 Conductor Material Bare Copper Connector on First End Bare Wire Device Supported Access Control Device, Security Device Jacket Material PVC Material Bare Copper Number of Conductors 2, 4, 6 Shielding Yes Solid or Stranded Stranded
TAA Compliant Yes
Cable Length 500' Color Yellow Insulation Material PP Package Type Reel Weight 47.70lb
Limited Warranty 3-Year
Environmental Certification RoHS Environmentally Friendly Yes Features Stranded Indoor/Outdoor Indoor
