FD9391-EHTV-V2 | T6-FD9391EH2
Please sign in to view pricing and availability and to add to cart.
Product Overview
VIVOTEK FD9391-EHTV-v2 is a newly revamped outdoor fixed dome network camera that delivers 3840x2160 (4K/8MP) resolution at up to 30 fps. This well-designed, outdoor-ready camera features a built-in microphone, I/O functionality, the most up to date VIVOTEK SNV, WDR Pro, and Smart IR III technology to deliver clear image quality in both low light and high contrast environments. It also offers a variety of built-in cybersecurity capabilities and AI-powered video analytics with IP66, IP67, IP6K9K, IK10+, NEMA 4X and wide temperature range from -40°C to 60°C without heaters making it ideal for wide-ranging outdoor surveillance scenarios.
Main Features
- 30 fps at 3840x2160
- H.265 Compression Technology with Smart Stream III
- Installation-friendly Design
- Weather-proof IP66, IP67, IP6K9K and Vandal-proof IK10+, NEMA 4X-rated Protection
- SNV (Supreme Night Visibility) for Low Light Conditions
- WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
- Built-in IR Illuminators up to 50M with Smart IR III
- Signed Firmware and Secure Boot
- AI-powered Smart Motion Detection and Smart VCA
- Cyber Protection via Trend Micro IoT Security
General Information
Specifications
ADI Part Number T6-FD9391EH2 Brand Name VIVOTEK Manufacturer Vivotek, Inc Manufacturer Part Number FD9391EHTVV2 Product Model FD9391-EHTV-v2 Product Name Fixed Dome Network Camera Product Series S Product Type Network Camera
Connectivity Technology Wired Field of View 110° ~ 43° (Horizontal) 57° ~ 24° (Vertical) 133° ~ 49° (Diagonal) Lens Type Varifocal Maximum Aperture f/1.38 Maximum Frame Rate 30 fps Minimum Focal Length 4.40 mm Night Vision Yes Night Vision Type Infrared Number of IR LEDs 4 Optical Zoom 2.3x
Night Vision Distance 164.04 ft Wide Dynamic Range Yes
Ingress Protection Rating IP66, IP67, IP6K9K NDAA Compliant Yes TAA Compliant Yes
Maximum Video Resolution 1600 x 1200
Maximum Operating Temperature 140°F (60°C) Minimum Operating Temperature -22°F (-30°C) Operating Humidity 98%
Longest Shutter Speed 1 Second Shortest Shutter Speed 1/100000 Second
Network (RJ-45) Yes
Lens Included Yes Maximum Focal Length 10.20 mm
Remote Management Yes
ADI Part Number Replaces T6-FD939EHTV Model Number Replaces FD9391-EHTV
Durability Dustproof, Impact Resistant, Vandalproof, Waterproof, Weatherproof Weight 3.06 lb
Input Voltage 12V DC, 24V AC
Diameter 6.9"
Recording Formats 4K Storage Type Memory Card
Maximum Resolution 1280 x 720
Limited Warranty 36-Month
Features Audio Detection, Back Light Compensation (BLC), Built-in Infrared Illuminator, Built-in Microphone, Day/Night, Face Detection, Highlight Compensation (HLC), Human Detection, Vehicle Detection, Wide Dynamic Range Impact Protection Rating IK10 Indoor/Outdoor Outdoor Package Contents - Fixed Dome Network Camera
- Quick installation guide
- product labels
- alignment sticker
- L-shaped wrench
- screw pack
- waterproof accessory pack
- sunshield
- and more below
