Comprehensive CPA-HDAE10 Pro AV/IT Integrator Series HDMI 8K Audio De-Embedder with ARC, EDID Management, Dolby Atmos
CPA-HDAE10|RH-CPAHDAE10
Comprehensive CPA-HDAE10 Pro AV/IT Integrator Series HDMI 8K Audio De-Embedder with ARC, EDID Management, Dolby Atmos
CPA-HDAE10|RH-CPAHDAE10
Comprehensive
Comprehensive CPA-HDAE10 Pro AV/IT Integrator Series HDMI 8K Audio De-Embedder with ARC, EDID Management, Dolby Atmos
CPA-HDAE10 | RH-CPAHDAE10
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Comprehensive's CPA-HDAE10 is an HDMI audio de-embedder that allows you to seamlessly de-embed audio from any HDMI source such as a projector, Blu-ray player, PC, streaming box, cable box, game consoles, ARC-compatible TVs and then output it to speakers, sound bar, audio amplifier or home entertainment sound systems. The CPA-HDAE10 is the ideal solution that can support both analog stereo sound and digital S / PDIF audio output simultaneously while keeping the audio and video clear on the HDMI output. The CPA-HDAE10 also supports the latest HDMI 2.1 and HDCP 2.3 standards. The CPA-HDAE10 is also ready for very high-quality 8K video at 60 frames per second. It has extra features to make it easier to set up, like adjusting for different types of cables. This makes it simple to connect your HDMI device to a stereo or surround sound system.
Main Features
- HDMI 2.1 and HDCP 2.3 compliant
- Supports 48 Gbps FRL and 18Gbps TMDS video bandwidth
- Supports video resolutions up to 8K at 60Hz 4:2:0 12bit, 4K at 120Hz 4:4:4 12 Bit
- HDMI 2.1 Protocols: VRR, ALLM, QMS, QFT, SBTM are supported
- HDR, HDR 10, HDR 10+, Dolby Vision, HLG pass-through
- LPCM 7.1CH, Dolby True-HD, Atmos and DTS-HD Master, DTS:X Audio pass-through
- HDMI Input audio or TV ARC audio de-embedded to S/PDIF and L/R audio output
- Supports CEC control from output devices to input sources
- Advanced EDID management
- Compact design for easy and flexible installation
General Information
Name: Comprehensive CPA-HDAE10 Pro AV/IT Integrator Series HDMI 8K Audio De-Embedder with ARC, EDID Management, Dolby Atmos
Category: Comprehensive, Residential AV, Pro AV, Residential Video Signal Distribution, Commercial Video Signal Distribution, HDMI Extenders, Pro HDMI Extenders
UPC Code: 808447086812
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number RH-CPAHDAE10 Brand Name Comprehensive Manufacturer Part Number CPA-HDAE10 Product Series Integrator
ADI Part Number Replaces RH-CPAHDA3 Model Number Replaces CPA-HDA3
