Adams Rite 4300-4M-202-313 Steel Hawk 4300 1-1/2" Electrified Deadlatch, Radius Mortised, Dark Bronze Anodized
4300-4M-202-313|R8-43004M202
Adams Rite 4300-4M-202-313 Steel Hawk 4300 1-1/2" Electrified Deadlatch, Radius Mortised, Dark Bronze Anodized
4300-4M-202-313|R8-43004M202
Adams Rite by ASSA ABLOY
Adams Rite 4300-4M-202-313 Steel Hawk 4300 1-1/2" Electrified Deadlatch, Radius Mortised, Dark Bronze Anodized
4300-4M-202-313 | R8-43004M202
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The 4300 Electrified Deadlatch seamlessly combines electrified locking hardware with access control while working within standard narrow stile aluminum entrance door preparations. Always operable from the inside via handle or paddle device. Entry via keyed mortise cylinder or access control device such as keypad or card reader. Fail secure lock with optional form "C" latch status monitor. The standard fail secure 4300 Electrified Deadlatch operates on 12, 16, or 24VDC power and is rated for continuous duty. Units are equipped with a quick connect plug-in type connector. Interchangeable without stile modification for MS Deadlocks or Adams Rite 4500 and 4900 Deadlatches. 1-3/4" [44.5mm] minimum door thickness required.
Main Features
- Steel with corrosion-resistant plating; Measures 15/16" x 5-13/16" x depth [23.8mm x 147.6mm x depth]; Depth varies by backset
- Stainless steel; Measures 5/8" x 1" x 5/8"[15.9mm x 25.4mm x 15.9mm] throw
- All metal; Deadlocks latchbolt to prevent "loiding" or case-knife entry
- Pick from optional strikes; 4304 surface mounted strike for easy retrofits; Specify 4901-01 mortised-flush version when covering existing MS deadlock preparation or for new applications; 4901-02 strike is available with radius profiles for pairs of doors and with extended lips of center-hung or thick door applications
- Individually boxed with strike plate, flat and radius faceplates, and mounting screws; Supplied with 4581 Universal Cam Plug to work with specified handles or paddle operators; Cylinder, paddle, handle available separately
- The 4600M with monitoring switch option cannot be used in conjunction with the 4300 Electrified Deadlatch
General Information
Name: Adams Rite 4300-4M-202-313 Steel Hawk 4300 1-1/2" Electrified Deadlatch, Radius Mortised, Dark Bronze Anodized
Category: Adams Rite by ASSA ABLOY, Access Control, Locking Devices, Electrified Deadlatches
UPC Code:
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number R8-43004M202 Brand Name Adams Rite by ASSA ABLOY Manufacturer Part Number 4300-4M-202-313 Product Type Door Lock Weight 1.25 lb
Material Metal, Stainless Steel
Height 6.88" Package Type Box Width 1"
Input Voltage 12V DC, 16V DC, 24V DC
Finishing Dark Bronze Anodized
Country of Origin US
