Minuteman EC2000RTXL2U Encompass RTXL On-Line Uninterruptible Power Supply, Double-Conversion, On-line, True Sine Wave, 2000VA, 1800W

EC2000RTXL2U | R1-90000782

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

Encompass Serie- high-end, true sine wave, Extended Runtime, Online UPS, rack/tower, 2000VA/1800W, 120V, power factor 0.9, (6) "Controllable" 5-15/20R Battery and Surge-protected receptacles, 3 min full load and 10 min half load runtime, load shedding, simultaneous RS-232, USB and optional SNMP communications, dedicated remote Emergency Power Off (EPO) port, SentryHD software compatible, 3-year warranty (including battery).

Main Features

  • True online, double-conversion technology
  • Compact case design, (only 2U for all models), for high-density rack installations
  • Compatible with external battery packs for unlimited runtimes
  • Flexible installation format- Rack or Tower
  • Rackmount ears come attached to UPS
  • Easy-to-read LCD display
  • Highly-efficient, Economy Mode option
  • Hot-swappable battery replacement
  • Simultaneous USB and RS232 communications
  • Compatible with Minuteman's SentryHD software

General Information

Name: Minuteman EC2000RTXL2U Encompass RTXL On-Line Uninterruptible Power Supply, Double-Conversion, On-line, True Sine Wave, 2000VA, 1800W
Category: Minuteman, Batteries & Power Supplies, Power Management, UPS
UPC Code:
Country of Origin: Taiwan, Province of China. Country of origin is subject to change.
