Image of NM-NAC3FXBWL
Shop all NEUTRIK

Neutrik NAC3FXXB-W-L AC Mains Cable Connector powerCON, Blue

NAC3FXXB-W-L|NM-NAC3FXBWL
Shop all NEUTRIK

Neutrik NAC3FXXB-W-L AC Mains Cable Connector powerCON, Blue

NAC3FXXB-W-L|NM-NAC3FXBWL

Sign In for Dealer Pricing

Become an ADI Customer
Image of NM-NAC3FXBWL
NEUTRIK

Neutrik NAC3FXXB-W-L AC Mains Cable Connector powerCON, Blue

NAC3FXXB-W-L | NM-NAC3FXBWL

Please sign in to view pricing and availability and to add to cart.

Overview
Specifications
Documents

Product Overview

IEC EN 60320-1 compliant. Accepted for cord sets as per IEC EN 60799:2021. Locking AC mains cable connector, keyed and color coded (grey) for power-out, screw terminal assembly, for cable diameters 10 - 16 mm. The powerCON FXXA/FXXB is a single phase (3 conductor) lockable power connector with Circuit Breaking Capability when mated with powerCON XX Series receptacles.It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed to guarantee a safe power connection.

Main Features

  • Easy and reliable twist lock system
  • Improved kink protection by two-component bushing
  • Superior NEUTRIK quality standard, extremely robust and reliable
  • Easy to assemble because the strain relief locks with the insert mechanically and aligns with the housing
  • Power-in (blue) and power-out (grey) versions with different keying to avoid the possibility of intermating
  • Unique NEUTRIK locking bushing and strain relief for cable diameters 10 mm to 16 mm
  • Ergonomic design with slip-proof two-component molded housing
  • IEC EN 60320-1 / UL 60320-1 / CSA C22.2 No. 60320-1 certified, thus accepted as a component for cord sets acc. to IEC 60799 / UL 817 and equipment acc. to IEC 62368-1

General Information

Name: Neutrik NAC3FXXB-W-L AC Mains Cable Connector powerCON, Blue
Category: NEUTRIK, Pro AV, Commercial Connector Cables, Pro Microphone Cables
UPC Code: 7613187017728
Country of Origin: Liechtenstein. Country of origin is subject to change.

Specifications

Product Documents and Resources

Product Data Sheet
Installation Instructions
Additional Resources
