OCC
OCC KMJL06U02 6-Position CAT3 Modular USOC Jack Connector, Black
KMJL06U02 | JQ-KMJL06U02
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
OCC's Category 5e Bezel jacks utilize our patented PC Board technology to exceed the TIA 568-C.2 Cat 5e requirements with headroom to spare. For a more cost effective solution, OCC also offers a Leadframe Bezel jack that utilizes our patented Leadframe technology. 110-style punch downs accommodate 22 AWG sold through 26 AWG solid and 24 AWG stranded conductors and each OCC jack offers universal T568A/B wiring and performance enhancements to exceed industry standards.
General Information
Name: OCC KMJL06U02 6-Position CAT3 Modular USOC Jack Connector, Black
Category: OCC, Data Comm & Networking, Cable Connectors, Inserts & Adapters
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number JQ-KMJL06U02 Brand Name OCC Manufacturer OCC Manufacturer Part Number KMJL06U02
Contact Plating Gold
Color Black
Environmental Certification UL Features 110 style IDC contacts, Available in 12 color options, Compliant with Power over Ethernet (PoE+) requirements, DC current rating- 1.5 A per conductor at 20 deg C ambient de-rated to 0.5 A at 60 deg C ambient, Dielectric withstand- 1000VAC RMS, AC 60Hz or 1414 VDC P-P, Fits all OCC Keystone faceplates and surface mount boxes, Insulation 500MOhm Minimum, Meets IEC 60603-7 requirements, One-piece stuffer cap included
