On-Q TRIG26262-I IG TR Decora Receptacle 15A 125V, Ivory
TRIG26262-I|H4-TRIG2626U
On-Q TRIG26262-I IG TR Decora Receptacle 15A 125V, Ivory
TRIG26262-I|H4-TRIG2626U
On-Q by Legrand
On-Q TRIG26262-I IG TR Decora Receptacle 15A 125V, Ivory
TRIG26262-I | H4-TRIG2626U
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Tamper-Resistant Isolated Ground Decorator Spec Grade Duplex Receptacle, Back and Side Wire, 15amp 125volt, Orange.
Main Features
- Dual mechanical shutter system to help prevent insertion of foreign objects
- Auto-ground clip assures positive ground
- Easily accessed break-off line-contact connecting tab for fast and easy split-circuit wiring
- Backed-out tri-drive brass terminal screws for faster installation
- Internal screw-pressure-plate back and side wire capability
- Two back wire holes for additional wiring flexibility
- Corrosion-resistant plated steel strap is locked in to face and back body to resist pulling away from the face / body assembly
- .032" Thick brass triple-wipe power contacts
- Two drive screws anchor steel strap to back body and face where abrupt removal torque is greatest
General Information
Name: On-Q TRIG26262-I IG TR Decora Receptacle 15A 125V, Ivory
Category: On-Q by Legrand, Batteries & Power Supplies, Electrical Cords & Connectors, Single & Duplex Outlets
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number H4-TRIG2626U Brand Name On-Q by Legrand Manufacturer Part Number TRIG26262-I Product Name Tamper-Resistant Isolated Ground Decorator Spec Grade Receptacle, Back and Side Wire, 15A, 125V, Ivory Product Type Receptacle
Color Ivory Depth 1.25" Height 3.625" Width 1.187"
Current Rating 15A
