On-Q by Legrand
On-Q TR5362-GRY Power Outlet, Duplex 20A/125V, Gray
TR5362-GRY | H4-TR5362GRY
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Introducing the On-Q by Legrand TR5362-Gray Power Outlet, a reliable and stylish solution for your electrical needs. This duplex outlet features a dual mechanical shutter system designed to prevent the insertion of foreign objects, ensuring safety in your home or office. With its unique circuit label on the face, you can easily identify circuits for convenience. Installation is a breeze thanks to the backed-out tri-drive brass terminal screws and the accessible break-off line-contact tab for split-circuit wiring. Enjoy added flexibility with two back wire holes and robust brass triple-wipe power contacts. Built to withstand high temperatures, this outlet operates efficiently in a range of conditions. Upgrade your space with the On-Q TR5362-Gray Power Outlet today!
Main Features
- Dual mechanical shutter system to help prevent insertion of foreign objects
- Exclusive patented feature, circuit label on face allows permanent circuit identification
- Easily accessed break-off line-contact connecting tab for fast and easy split-circuit wiring
- Backed-out tri-drive brass terminal screws for faster installation
- Internal screw-pressure-plate back and side wire capability
- Two back wire holes for additional wiring flexibility
- 0.032 inch thick brass triple-wipe power contacts
- Two drive screws anchor steel strap to back body and face where abrupt removal torque is greatest
- Temperature Rise; Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature; Maximum continuous 60°C, minimum -40°C without impact
General Information
Name: On-Q TR5362-GRY Power Outlet, Duplex 20A/125V, Gray
Category: On-Q by Legrand, Batteries & Power Supplies, Electrical Cords & Connectors, Single & Duplex Outlets
UPC Code: 785007243796
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number H4-TR5362GRY Brand Name On-Q by Legrand Manufacturer Part Number TR5362-GRY Product Name 20A 125V Construction Spec-Grade Tamper-Resistant Duplex Receptacle, Back and Side Wire, Gray Product Type Duplex Receptacle
Receptacle Type Tamper-Resistant
Color Gray Depth 1.13" Height 2.635" Width 1.322"
Current Rating 20A Voltage Rating 125V
Limited Warranty 1-Year
Certifications & Standards CSA C22.2 No. 42, UL498
