EtherWAN EX32008 Industrial Unmanaged Ethernet Switch
EX32008 | ET-EX32008
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
EtherWAN's EX32008 Series is a industrial unmanaged Fast Ethernet switching platform, designed for easy deployment in harsh environments. The EX32008 Series supports 12 to 48V DC redundant power input, and also provides relay alarm while power failure or port link down occur. The EX32008 is equipped with eight Fast Ethernet ports, or a combination of Fast Ethernet copper ports and one 100FX port for long distance connectivity. This versatile switch features 10/100Mbps transfer speeds, full/half-duplex auto-negotiation and auto MDI / MDIX operation allowing you to connect your network devices without hassles. The EX32008 is feature-rich with full wire speed Fast Ethernet throughput, QoS (Quality of Service), and IEEE802.3az EEE (Energy Efficient Ethernet). The EX32008 Series is built with relay alarm to notify users when power fails or link down occurs. It also supports port link down alarm by enabling the DIP switch. The EX32008 Series is housed with DIN rail mountable plastic compact case which is an ideal solution for applications in harsh environments.
Main Features
- Industrial Grade
- Supports -10 to 60°C (14 to 140°F) operating temperature
- Up to one 100BASE-FX port with SC, ST, WDM options
- Fanless design
General Information
Name: EtherWAN EX32008 Industrial Unmanaged Ethernet Switch
Category: EtherWAN, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number ET-EX32008 Brand Name EtherWAN Manufacturer Part Number EX32008
Network Switch Type Unmanaged
