Product Overview
EtherWAN's EX73900E series is a hardened DIN-rail mounted managed Ethernet switch platform. Equipped with up to 12 gigabit Ethernet and 4 dual-rate gigabit SFP ports, and the IEEE1588v2 Precision Time Protocol (PTP) that uses network packets and time stamps for network time synchronization. The EX73900E series provides flexibility, speed, and reliability to support networks for urban infrastructure, transportation, security, power substations, and other areas where connectivity is crucial.
Main Features
- IP40 Protection Level
- Integrated with 2 DIs (Digital Input) and 2 Relay Output
- Supports static routes, RIP v1/v2, and VRRP
- Dual Rate gigabit SFP ports
General Information
Name: EtherWAN EX73924E-0VB Hardened 12-Port Gigabit Ethernet Switch
Category: EtherWAN, Data Comm & Networking, Hubs, Routers & Switches, Network Switches
UPC Code: 0847653005477
Country of Origin: Taiwan, Province of China. Country of origin is subject to change.
Specifications
ADI Part Number ET-73924E0VB Brand Name EtherWAN Manufacturer Part Number EX73924E-0VB
Material Aluminum Power Consumption 20W
Manageable Yes
Networking Standards IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Depth 5.5" Height 6.7" Width 2.8"
Input Voltage 12-48V DC
Mount Type Din Rail Mount
Limited Warranty Lifetime
Environmental Certification FCC, UL Environmentally Friendly Yes Package Contents 1 Console Cable, Ethernet Switch, Mounting brackets, screws, Quick Install Guide
