SoundTube CM82-BGM-II-WH SoundTube 8" In-Ceiling Background Music Speaker, White Seamless Magnetic Grille
CM82-BGM-II-WH|9W-CM82BGMIW
SoundTube CM82-BGM-II-WH SoundTube 8" In-Ceiling Background Music Speaker, White Seamless Magnetic Grille
CM82-BGM-II-WH|9W-CM82BGMIW
SoundTube
SoundTube CM82-BGM-II-WH SoundTube 8" In-Ceiling Background Music Speaker, White Seamless Magnetic Grille
CM82-BGM-II-WH | 9W-CM82BGMIW
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
One 8.0 inch (203 mm) polypropylene woofer with butyl rubber surround and one 1.0 inch (25 mm) silk dome tweeter. BroadBeam Ring technology for mid-range clarity and smooth off axis performance. Easy-access six-position tap switch for 25/70.7/100-volt and transformer bypass settings allows for easy ordering, stocking and installation. Tuned port on baffle for added musicality and bass response down to 55 Hz (-10 dB). Reduced amplification costs and maximum efficiency of 86.0 dB sensitivity, 16 ohm impedance. Incorporates a painted steel magnetic seamless grille for lasting durability and refined aesthetics. Adaptable to material thicknesses ranging from 0.035 inch (0.9 mm) to 1.6 inch (40.6 mm). UL 1480 and 2043 listed.
General Information
Name: SoundTube CM82-BGM-II-WH SoundTube 8" In-Ceiling Background Music Speaker, White Seamless Magnetic Grille
Category: SoundTube, Pro AV, Commercial Audio, Pro Speakers
UPC Code: 644216225705
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number 9W-CM82BGMIW Brand Name SoundTube Manufacturer Part Number CM82-BGM-II-WH
Maximum Frequency Response 22 kHz Minimum Frequency Response 45 Hz
Color White
Environmental Certification CE, RoHS, UL Environmentally Friendly Yes Package Contents Conduit Plate, Euroblock, Grille, Paint Mask, Tile Bridge
