APC BVS480XDPDR Industrial Easy UPS Control Module, 24V DC, DIN Rail, 20A
BVS480XDPDR|2G-S480XDPDR
APC BVS480XDPDR Industrial Easy UPS Control Module, 24V DC, DIN Rail, 20A
BVS480XDPDR|2G-S480XDPDR
APC by Schneider Electric
APC BVS480XDPDR Industrial Easy UPS Control Module, 24V DC, DIN Rail, 20A
BVS480XDPDR | 2G-S480XDPDR
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
The Industrial UPS 24V DC DIN Rail is a part of the Schneider Electric's Easy UPS family. This model is a 480W UPS that offers DC input to DC output for industrial equipment support. It features 0-5V signaling relay contacts, up to 4 total external battery pack support, LED indicators and EPO switch for better control over the indutrial controls infrastructure. It comes with a 2-year standard warranty.
Main Features
- Prevents power outage by providing reliable buffering of DC voltage for many hours
- Prevent critical data loss by staying powered during a blackout with up to 480 W load capacity
- 12 Hour typical battery recharge time to allow optimal performance for longer hours with added efficiency
- Lead Acid battery chemistry to better suit your requirements with maximum productivity
- Terminal Block plug/connector type for maximum usability with added reliability
- DC Power receptacle type offers ease of operation with maximum efficiency
- 24 V DC input voltage for maximum feasibility and added productivity
- 24 V DC output voltage for optimal performance with maximum feasibility
- DIN Rail form factor Is the strongest, most adaptable mounting system with maximum usability
General Information
Name: APC BVS480XDPDR Industrial Easy UPS Control Module, 24V DC, DIN Rail, 20A
Category: APC by Schneider Electric, Batteries & Power Supplies, Power Management, UPS
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 2G-S480XDPDR Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number BVS480XDPDR Packaged Quantity 1 Product Line Easy UPS Product Model BVS480XDPDR Product Name Easy UPS BVS480XDPDR 480W DIN Rail UPS Product Type DC UPS
Output Voltage 24V DC Receptacle Type DC Power
Battery Characteristics External Battery System Battery Chemistry Lead Acid Battery Recharge Time 12-Hour DC System Voltage 24 V DC
Maximum Operating Elevation 9842.52 ft Maximum Storage Elevation 9842.52 ft Sound Emission 40 dB
Color Silver Depth 4.7" Form Factor DIN Rail Height 5.1" Weight 1.10 lb Width 1.6"
Input Voltage 24V DC Plug/Connector Type Terminal Block
Additional Warranty Information 2 years repair or replace Limited Warranty 2-Year
Environmental Certification RoHS Environmentally Friendly Yes Package Contents - Easy UPS BVS480XDPDR 480W DIN Rail UPS
- User Manual
