APC APDU9981NA3 Rack Mount PDU 9000 Switched, ZeroU, 21-Port C13/C15, 3-Port C19/C21, 11.5kW, 200-240V
APC APDU9981NA3 Rack Mount PDU 9000 Switched, ZeroU, 21-Port C13/C15, 3-Port C19/C21, 11.5kW, 200-240V

APC APDU9981NA3 Rack Mount PDU 9000 Switched, ZeroU, 21-Port C13/C15, 3-Port C19/C21, 11.5kW, 200-240V
APDU9981NA3 | 2G-DU9981NA3
Please sign in to view pricing and availability and to add to cart.
Product Overview
With Industry leading reliability, manageability, and security, APC Switched Rack PDU's provide advanced load management plus on/off outlet level power cycling and sequencing control.
Switched Rack PDUs enable advanced, customizable power control and active monitoring for datacenter and edge environments. Remote outlet level control allows on/off power cycling to remotely reboot equipment and restrict unauthorized use of individual outlets to reduce downtime. Outlet power sequencing and grouping allow users to specify the order of device power up or down to avoid circuit overload due to inrush current and/or load shed to conserve energy. Power metering provides real-time remote monitoring of connected loads with alarms to warn of potential overloads. Users can access, configure, and control Switched Rack PDUs through secure Web or SNMP and are fully compatible with EcoStruxure IT. New 9000 series Switched Rack PDUs include Gigabit ethernet, 1% Metering accuracy, 60C Operating temperature (select models) with new C13/C15 and C19/C21 hybrid outlets, ability to share 1 network port across 32 PDUs, and enhanced cybersecurity.
Main Features
- with a built-in digital current meter avoid potential overloads via switched PDUs
- IEC 60320 C13/C15 receptacle type to ensure maximum usability and reliable power output
- Single Phase phase PDU provides optimal power output with added usability
- IEC 60309 20A 3P+N+PE plug/connector type for reliable, productive connectivity and optimal power output
- 415 V input voltage for optimal performance with maximum usability
- 208 V AC output voltage for better reliance and maximum usability
- 208 V AC output voltage for optimal performance with maximum feasibility
General Information
Specifications
ADI Part Number 2G-DU9981NA3 Brand Name APC by Schneider Electric Manufacturer Schneider Electric SA Manufacturer Part Number APDU9981NA3 Product Name Rack PDU 9000 Switched, ZeroU, 11.5kW, 208V, (21) C13/C15 & (3) C19/C21 Product Series 9000 Product Type PDU Sector Data Comm & Networking
Output Voltage 208V, 240V PDU Type Switched Phase Single Phase Receptacle Detail 21 x IEC 60320 C13/C15, 3 x IEC 60320 C19/C21 Receptacle Type IEC 60320 C13/C15, IEC 60320 C19/C21
Network (RJ-45) Yes
Remote Outlet Switching Yes
Depth 1.81" Height 70.51" Rack Height 0U Weight 15.43lb Width 2.17"
Input Current 16A Input Voltage 415V Plug/Connector Type IEC 60309 20A 3P+N+PE
Mount Type Rack Mount Protection Type Circuit Protection
Limited Warranty 3-Year
Environmental Certification cUL Listed, FCC Part 15 Class A, PSE, WEEE Environmentally Friendly Yes Package Contents - Rack PDU 9000 Switched, ZeroU, 11.5kW, 208V, (21) C13/C15 & (3) C19/C21
- Installation guide
- Rack mounting brackets
- Safety guide
