APC GVMSB180KG65S Galaxy VM 180 kVA UPS Single 480-480V, 65kAIC, Start up 5x8
GVMSB180KG65S|2G-B180K65S
APC GVMSB180KG65S Galaxy VM 180 kVA UPS Single 480-480V, 65kAIC, Start up 5x8
GVMSB180KG65S|2G-B180K65S
APC by Schneider Electric
APC GVMSB180KG65S Galaxy VM 180 kVA UPS Single 480-480V, 65kAIC, Start up 5x8
GVMSB180KG65S | 2G-B180K65S
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
A highly compact, energy efficient, 65kAIC rated 3-phase UPS for data centers, facility and industrial applications.
Main Features
- Compact 180 kVA UPS for data centers
- Energy efficient 3-phase design
- 65kAIC rating for high reliability
- Supports 480-480V input/output
- Ideal for facility and industrial use
- Includes start-up service 5x8
General Information
Name: APC GVMSB180KG65S Galaxy VM 180 kVA UPS Single 480-480V, 65kAIC, Start up 5x8
Category: APC by Schneider Electric, Batteries & Power Supplies, Power Management, UPS
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 2G-B180K65S Brand Name APC by Schneider Electric Manufacturer Part Number GVMSB180KG65S Packaged Quantity 1 Product Line Galaxy VM Product Name Galaxy VM 180 kVA UPS Single 480-480V Product Type Industrail UPS Weight 1497.9lb
Output Voltage 480V Overload Protection Yes Phase Three Phase
Maximum Operating Humidity 0.95
Energy Star Yes
Maximum Operating Elevation 3333' Maximum Operating Temperature 104?F Maximum Storage Temperature 5°F Minimum Storage Temperature 104°F Thermal Dissipation 6201.3W
Application/Usage Data Center, Industrial Color White Depth 33.6" Height 77.6" Package Type Pack Width 39.4"
Input Voltage 480V Output Frequency 50Hz|60Hz Plug/Connector Type Hard Wire 4-wire (3PH + G), Hard Wire 5-wire (3PH + N + G) Waveform Type Sine Wave
Limited Warranty 1-Year
Environmental Certification FCC, Green Premium, RoHS, UL Environmentally Friendly Yes
