C2G CG31346 C2G CG-31346 CAT6 Snagless Unshielded (UTP) Ethernet Network Patch Cable, 5' (1.5m), Yellow
CG31346|2D-CG31346
C2G CG31346 C2G CG-31346 CAT6 Snagless Unshielded (UTP) Ethernet Network Patch Cable, 5' (1.5m), Yellow
CG31346|2D-CG31346
C2G by Legrand
C2G CG31346 C2G CG-31346 CAT6 Snagless Unshielded (UTP) Ethernet Network Patch Cable, 5' (1.5m), Yellow
CG31346 | 2D-CG31346
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
With Cables To Go's Cat6 550Mhz Snagless Patch Cables you can stay ahead of the game with the use of this high-speed cabling to distribute data, voice and video. These cables will deliver stable performance to 550 MHz. Each meets EIA/TIA Cat 6 TIA/EIA- 568-B-2.1, draft 9 standards. These cables will handle bandwidth intensive applications up to 550 Mhz and beyond and drastically reduce both impedance and structural return loss (SRL) as compared to standard 100 Mhz wire! Constructed with high-quality cable and a shortened body plug, this design will keep Near-End Crosstalk (NEXT) levels to a minimum. The molded, snag-free boot prevents unwanted cable snags during installation and provides strain-relief. Cables To Go Cat6 550Mhz Snagless Patch Cables are available in a variety of colors to easily color-code your network installation. \r\n- Connector: 50-micron gold plated RJ-45 Male to Male \r\n- Conductor: 24 AWG Stranded Copper \r\n- Jacket: PVC \r\n- Molded, Snag-Free boot prevents unwanted cable snags \r\nApplications: \r\n- Gigabit 1000 BASE-T; 100 BASE-T; 10 BASE-T (IEEE 802.3) \r\n- 4/16 Mbps Token Ring (IEEE 802.5); 100 VG-AnyLAN \r\n- 100 Mbps TP-PMD (ANSI X3T9.5); 55/155 Mbps ATM \r\n- Voice; T1 \r\n- High bandwidth applications such as 622 ATM, Wideband\r\n- Designed For: Network Adapters, Hubs, Switches, Routers, DSL/Cable Modems, Patch Panels and other twisted-pair applications \r\n- Standard: Category 6 TIA/EIA- 568-B-2.1, draft 9
Main Features
- High-speed Cat6 550MHz performance
- Meets EIA/TIA Cat 6 TIA/EIA-568-B-2.1 standards
- Reduces impedance and structural return loss
- Molded, snag-free boot for easy installation
- 50-micron gold plated RJ-45 connectors
- 24 AWG stranded copper conductor
- PVC jacket for durability
- Supports Gigabit Ethernet and high bandwidth applications
- Compatible with network adapters, hubs, switches, routers
- Available in various colors for easy network coding
General Information
Name: C2G CG31346 C2G CG-31346 CAT6 Snagless Unshielded (UTP) Ethernet Network Patch Cable, 5' (1.5m), Yellow
Category: C2G by Legrand, Wire & Cable, Pro AV, Network Patch Cords, Commercial Connector Cables, Pro Patch Cables, Category 6 Patch Cords, Pro USB Cables
UPC Code: 757120313465
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 2D-CG31346 Brand Name C2G by Legrand Manufacturer Part Number CG31346
American Wire Gauge 24AWG Cable Type Category 6 Connector on First End RJ-45 Male Connector on Second End RJ-45 Male Solid or Stranded Stranded
NDAA Compliant Yes TAA Compliant No
Cable Length 5' Color Yellow
Environmental Certification REACH, ROHS, Prop 65, TSCA, NDAA 889
